End Closure For Plastic Pipes Offering Lightweight Design with Thin Wall and Large Contact Area to Improve Sealing Efficiency

Large Image : End Closure For Plastic Pipes Offering Lightweight Design with Thin Wall and Large Contact Area to Improve Sealing Efficiency

Product Details:

Place of Origin:	BEIJING, CHINA
Brand Name:	TH
Certification:	ISO9001
Model Number:	DN 1200

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Packaging Details:	Standard export wooden cases
Delivery Time:	5~15 work days
Payment Terms:	T/T,L/C,Western Union,MoneyGram,D/P,D/A
Supply Ability:	20 sets per month

Contact Now

Detailed Product Description

Product Name:	End Closure For Plastic Pipes Offering Lightweight Design With Thin Wall And Large Contact Area To Improve Sealing Efficiency	Standards:	GB/T 6111, EN921, ISO1167, ASTM D 1598/1599
Exterior Size(mm*mm):	φ1360*600mm	Material:	304# Stainless Steel Or Carbon Steel
Model:	DN 1200mm	Working Principle:	Sealing The Testing Pipes With High Temperature Resistant Silicone Seal Rings Embedded In The Stainless Steel Or Carbon Steel Closures Seal Groove, The Closures Metal Rings Press The Silicone Seal Rings.
Color:	Silvery White	Product Category:	Plastic Pipe End Caps
Highlight:	lightweight plastic pipe end closure , thin wall pipe end cap , large contact area pipe seal

End Closure For Plastic Pipes

Lightweight design with thin wall and large contact area to improve sealing efficiency

Product Overview

This series of Plastic Pipe End Caps, engineered for hydrostatic testing in accordance with ASTM D1598/D1599 standards, adopts an A-type radial sealing design and is fabricated from precision-machined castings. The primary components are constructed from premium-grade stainless steel or carbon steel, while auxiliary parts are made of stainless steel or plastic-sprayed carbon steel—endowing the caps with exceptional compressive strength and superior corrosion resistance for prolonged service life.

As a patented technical product, it features a rationally optimized structure, delivering outstanding sealing performance, hassle-free installation, and a 100% clamping success rate.

Key Features

Drum-Shaped Sealing End: Provides large force-bearing area, requires low applied pressure, and features thin-walled construction for reduced weight and easy transportation
Serrated Clamping Interface: Enhances clamping force and prevents specimen slippage for high operational success rate
Leakage-Proof O-Ring Sealing: Axial deformation unaffected by clamping force, eliminating medium leakage risk
Cross-Brand Compatibility: Standard interface ensures compatibility with XGY-series test mainframes and other international testing equipment
Complete Pre-Assembled Configuration: Includes all essential accessories (bolts, O-rings, vent valves) for immediate deployment
Precision Casting Technology: Semi-circular pot-shaped form ensures seamless fitting and zero leakage during testing

Technical Parameters

Parameter	Value
Max. Diameter (mm)	φ1400
Height of one end (mm)	600
Weight of one end (KG)	400
O-ring size (mm)	φ1195*25
Max. pressure (Mpa)	1.6
Nominal value (Mpa)	1.0

Compliance Standards

ASTM D1598-2004, ASTM D1599, GB/T6111-2018, GB/T15560-1995, GB/T18252-2008, GB/T18476-2001, etc.

Support & Services

Our dedicated technical support team provides comprehensive assistance for installation, commissioning, and operational application. We offer product documentation, troubleshooting guidance, and industry best practices to ensure optimal performance and extended service life.

Additional services include custom dimensioning, personalized labeling, OEM production solutions, and private branding to meet your specific requirements.

Packaging & Shipping

Supplied in pairs (2 units per set) and packaged in export-grade reinforced wooden crates. Each end cap is individually protected with scratch-resistant film and shock-absorbent cushioning.

Standard Shipping: 5-15 business days

Expedited Shipping: Available upon request

Frequently Asked Questions

What is the official model designation of this product?

The model designation for this product is XGY (the standard model code for our hydrostatic test end cap series).

Does this product possess relevant quality or system certifications?

Yes, this product is covered by our company's ISO 9001 quality management system certification.

What is the minimum order quantity (MOQ) required for this product?

The minimum order quantity (MOQ) for this product is 1 complete set, with flexible bulk-order terms available.
