And User Friendly End Closure For Plastic Pipes Designed To Provide Quick Installation And Effective Sealing Performance

Large Image : And User Friendly End Closure For Plastic Pipes Designed To Provide Quick Installation And Effective Sealing Performance

Product Details:

Place of Origin:	BEIJING, CHINA
Brand Name:	TH
Certification:	ISO9001
Model Number:	XGY

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Packaging Details:	Standard export wooden cases
Delivery Time:	3~5 work days
Payment Terms:	T/T,L/C,Western Union,MoneyGram,D/P,D/A
Supply Ability:	1000 sets per month

Contact Now

Detailed Product Description

Product Name:	And User Friendly End Closure For Plastic Pipes Designed To Provide Quick Installation And Effective Sealing Performance	Model:	φ 75mm
Applicable Pipe's Diameter:	φ75~φ75+0.8mm	Sealing Ring:	O-ring
Material:	304# Stainless Steel	Exterior Size(mm*mm):	φ145*105mm
Fixture Structure:	Half Round Pot Form,easy For Installation , No Leakage, Convenient Operation	Max. Pressure:	10MPA
Type:	A
Highlight:	user-friendly plastic pipe end closure , quick installation pipe end cap , effective sealing plastic pipe cap

User-Friendly End Closure for Plastic Pipes

Product Overview

Our Plastic Pipe End Caps are available in Type A and Type B configurations, fully compliant with ISO 1167 standards for pipe hydrostatic and bursting testing. With a maximum pressure rating of 16 MPa, these pre-assembled complete units include all essential components: fastening bolts, O-type sealing rings, and vent valves.

Fixture Structure

Crafted with precision casting technology and featuring a half-round pot-shaped structure, these end caps ensure hassle-free installation, leak-proof performance, and highly user-friendly operation.

Never compromise on the quality of your pipe end caps. Opt for our Plastic Pipe End Caps to secure robust, long-lasting solutions that perfectly cater to the pressure testing requirements of thermoplastic piping systems.

Key Features

Product Name: Plastic Pipe End Caps
Sealing Ring: O-ring
Working Principle: Used for sealing test pipes with high-temperature resistant silicone seal rings embedded in the end caps seal groove
Weight: 1.6KG
Type: A
Precision casting, half round pot form, easy installation, no leakage, convenient operation
End-shield cover for short-term pressure test for leaktightness of assemblies
End caps for end-load-bearing and non-end-load-bearing assemblies and joints for thermoplastics pressure piping

Technical Parameters

Meet Standard	ISO1167, ASTM D 1598/1599
Product Category	Plastic Pipe End Caps
Material	304# Stainless Steel
Max. Pressure	12MPA
Applicable Pipe Diameter	φ32~φ32+0.3mm
Delivery Time	3~5 days
Weight	1.6KG
Exterior Size	φ75*60mm
Technics	Precision Casting
Seal Ring Size	φ30*3.5mm

Applications

Constructed from premium 304 stainless steel, the XGY Plastic Pipe End Caps fully comply with ISO 1167 and ASTM D 1598/1599 standards. With an outline dimension of φ75×60 mm and maximum pressure rating of 12 MPa, these components deliver versatile performance across various operational scenarios.

A primary application is pairing with Plastic Pipe Hydrostatic Pressure Testing Machines, where they function as specialized end closures for thermoplastic pressure piping systems. As critical components for long-term hydrostatic strength testing, the XGY end caps form secure airtight seals around pipe specimens, preventing pressure leakage and ensuring accurate test data.

Support and Services

We provide comprehensive technical support and after-sales services to guarantee full customer satisfaction. Our team of seasoned technical specialists offers professional assistance covering equipment installation guidance, targeted troubleshooting solutions, and routine maintenance advisory services.

We also offer tailor-made customization solutions to address unique operational requirements. Our engineering team collaborates closely with clients to design and manufacture end cap products that precisely align with specific dimensional, pressure rating, and application demands.

Frequently Asked Questions

Q1: What is the model number for these plastic pipe end caps?
A1: The official model number is XGY.
Q2: Do these end caps come with relevant certification?
A2: Yes, they are certified under the ISO 9001 quality management system.
Q3: Where are these end caps produced?
A3: Manufactured at our dedicated production facility in Beijing, China.
Q4: What is the minimum order quantity?
A4: The minimum order quantity is 1 set.
Q5: What is the monthly supply capacity?
A5: We can provide 1000 sets per month.
Q6: What packaging is used?
A6: Packaged in standard export-grade wooden cases for shipping integrity.
Q7: What payment terms are available?
A7: Available payment terms include T/T, L/C, Western Union, MoneyGram, D/P, and D/A.
